Manual phoropter RT3000

Ø  Adopting ergonomic operation with large scale and improving performance.

Ø  Automatically interlock between cross -cylinder lens and lens coordinates

Ø  More accurate, comfortable and easier to operate

Cylinder range:

0.00D ~ -6.00D (Step: 0.25D)

( 0.00D~ 8.00D with auxiliary lens of-2.00D) (Step:0.25D)

Cylinder axis:

0 to 180°, step: 5°

Cross-cylinder lens:

 ±0.25D

Rotary prisms:

 0 to 20,1 steps

P.D.adjustment:

 48-75mm, 1mm steps

Dimensions:

 320×295×97(mm)

Net weight:

4.5Kg

Standard accessories

near point card,reading rod dust cover,face mat,Lens accessorial instrument

Convergence adjustment

∞, 380mm(when P.D. 64mm)

Forehead rest adjustment

16mm

Standard accessory lens

circinal lens,double even lens
